DolicraftPDFDesigner
Visual Drag-and-Drop PDF Template Editor for Dolibarr. Compatible Dolibarr V16 to V23. GPLv3. No external dependencies. By Dolicraft.
Full description
DolicraftPDFDesigner - Visual Drag-and-Drop PDF Template Editor for Dolibarr
DolicraftPDFDesigner for Dolibarr. Compatible V16 to V23. GPLv3 license. No external dependencies.
Features
1. Browser-Based Visual Editor
Design your PDF templates directly in your web browser. A 3-column layout: block palette on the left, A4 page preview in the center, properties panel on the right.
2. 8 Block Types
Logo, static text, dynamic Dolibarr field (variables), lines table, totals block, horizontal separator, colored rectangle, and custom image. Each block has full property controls.
3. All Dolibarr Variables
Access every standard variable: ref, date, client name/address, amounts (HT, TVA, TTC), payment terms, public/private notes, and all extrafields.
4. Lines Table with Column Configuration
Configure which columns appear in the invoice lines table, their width, headers, and alignment. Supports: description, quantity, unit price, VAT rate, line total.
5. Live PDF Preview
Click Preview to generate an actual PDF with your current design, using either sample data or a real document from your database.
6. 3 Pre-Built Templates
Three professional templates are installed automatically: Modern (clean, blue accent), Classic (full borders, traditional), Minimal (lots of whitespace). Use them as-is or as starting points.
7. Undo/Redo and Keyboard Shortcuts
Full undo/redo stack (Ctrl+Z/Y). Delete blocks with Delete key. Arrow keys for precise positioning. Ctrl+S to save.
8. Export/Import as JSON
Share templates between Dolibarr installations by exporting as JSON and importing on another instance.
Requirements
Dolibarr V16 to V23
PHP 7.4 to 8.3
No external dependencies
Installation
Download ZIP from DoliStore
Extract to htdocs/custom/
Enable in Setup > Modules
Configure in module settings
Support
Email: contact@dolicraft.com | Website: dolicraft.com
